![[field:text/]](/uploads/allimg/181217/1-1Q21G52940.jpg)
| 型号 model | VS-300 | |
| 结构 structure | 直角坐标 rectangular coordinates type | |
| 轴数 axis no. | 3 | |
| 大加速度X轴/Y轴/Z轴(g) max acceleration X/Y/Z(g) | 1g/1g/0.5 | |
| 运动范围X轴/Y轴/Z轴(mm) motion range X/Y/Z(mm) | 300/300/100 | |
| 速度范围(mm/s) speed range(mm/s) | X轴/Y轴X/Y | 1000 |
| Z轴Z | 500 | |
| 重复定位精度(mm) repositioning accuracy(mm) | X轴/Y轴/Z轴 X/Y/Z | ±0.015 |
| 分辨率(mm) resolution(mm) | X轴X | 0.004 |
| Y轴Y | ||
| Z轴Z | ||
| 载物板负载(kg) loading-plate load(kg) | 10 | |
| Z轴负载(kg) Z axis load(kg) | 5 | |
| 功率(W)power(W) | 450 | |
| 驱动方式 driving type | 交流伺服AC servo | |
| 传动方式transmission type | 研磨丝杆lead screw | |
| 编程方式programming type | 基于PC机开发 Based on PC development | |
| 相机像素(万像素) camera pixel | 130-2000万像素 1.3M-20M pixel | |
| 光源light source | LED（蓝色或红色） LED(Blue or red) | |
| 重量（kg）wet.(kg) | 76 | |
| 外形尺寸（长×宽×高）(mm) dimension (L*W*H) | 576×514×626 | |
| 输入电压input voltage | 220V AC 50Hz | |
| 工作环境work environment | 温度0-40℃ 湿度20-90%（不结露） Temperature 0-40℃, Humidity 20-90% (No condensation) | |
